Products

New Products

4 Lan N97 DDR4 Fanless Mini Firewall Router

♦Model No.:C2120Z-L4 V2.0(N97)

♦All aluminum alloy, fanless cooling structure

♦Intel®Alder Lake-N N97/Turbo 3.6GHz quad-core CPU

♦1x DDR4 RAM slot, up to 16GB

♦1x SATA + 1x M.2

♦4x RJ45 Lan

♦1x HDMI1.4

♦1x Mini-PCIe for 4G/WIFI

♦5x USB3.0, 1x USB2.0

♦DC_12V Power Input
8 Lan LGA1151 DDR4 SFP Pfsense System Security Firewall Device

♦ Model No.:R320E-L8 V1.0(R270)

♦ Intel®LGA1151 6th/7th/8th/9th i3/i5/i7 series processor

♦ Intel®Q270/Q250 High speed chipset

♦ 2*DDR4 SODIMM 2400MHz ,max up to 64GB

♦ 8*Intel I210 Gigabit Ethernet port，4 or 2 SFP+ ports can be extended

♦ 2*USB3.0, 1*VGA

♦ 4 or 2 light ports can be extended

♦ Support two groups of BYPASS(Optional)

♦ Standard with 1U AC220V ATX power supply 250W

♦ 1U standard case, high-quality galvanized steel plate / Support Windows&Linux OS
4 Lan N97 DDR4 Machine Vision Motherboard

♦Model No.:ITX-VL305 VER:1.0(N97)

♦Based on Inte Alder Lake-N SOC platform

♦Integrated Intel®Alder Lake-N N97 3.6GHz quad-core processor

♦Intel® UHD Graphics; VGA+HDMI+LVDS/1* EDP for display

♦1*DDR4 2133MHz SO-DIMM Socket, up to 16GB

♦4* Intel WGI210AT Gigabit Ethernet/ 8*USB/ 6*COM /1*SIM/ 1* TPM

♦1*SATA3.0/ 1* M.2 SSD/ 1* Mini-PCIE (Wifi/4G)

♦Support GPIO ; Watchdog Timer ; Audio power amplifier 4Ω/3W

♦Support DC_12V Input
RK3576 ARM Motherboard

♦Model No.:CX3576-A V1.0 (4G+128G) VER:4G

♦WIFI use FCS960K,support 2.4G/5G dual-band,Bluetooth5.3

♦Bottom plate thread DC2.0*1（12V-36V input)

♦RJ45*1、HDMI*1、USB3.0*1、USB2.0*1、USB2.0 socket*4、TF*1、Audio 3.5mm*1

♦Size:157*100mm

6 Lan N150 2.5G DDR4 Mini Firewall Appliance
♦ Model: SII-H31FX-N150_6L

♦ Intel N150 Processor

♦ Memory:1xSO-DIMM 3200MHz DDR4, up to 16GB

♦ Display: 1xDP, 1xHDMI displays

♦ Ethernet: 6x 2.5 GbE Ports

♦ Storage:1x M.22280 NVME SSD,1x SATA3.0

♦ Expansion:1x MINIPCIE (WIFI&BT/4G)

♦ Power: DC 12V

♦ Size: 178 x 126 x 56mm

Read More Make an inquiry
LGA1700 DDR5 SFP 6 Lan 2.5G Firewall
♦Model: SII-B760-6LV (440 * 320 * 45 mm)

♦CPU: Intel 12th ~14th Gen LGA1700 Processors

♦Memory: 2x SO-DIMM DDR5 5600MHz slot, up to 64GB

♦Ethernet: 6x RJ45_2.5GbE (Intel I225/I226V Ethernet Controller)

♦Storage: 2x M.2 NVME slot + 4x SATA3.0 slot

♦Expansion: Supports expand 2/4x SFP+_10G ports; 1x M.2 E-KEY (for WIFI&BT); 2x M.2 B-KEY(for 4G/5G)

♦Power Supply: AC 100-240V (Dual power supply is optional)

Read More Make an inquiry
Ultra 5 325 Dual Lan DDR5 Industrial AI Motherboard
♦ Model: ITX-YH404M1_I523L

♦ CPU: Panther Lake Ultra 5 Processor 325; NPU TOPS (Int8) 47

♦ Memory: Dual channel SO-DIMM DDR5 up to 64GB

♦ Display: Intel® Graphics GPU TOPS (Int8) 40; VGA+2* HDMI+LVDS/EDP displays

♦ Ethernet: 2* I210AT GbE Ports

♦ Storage: 1* SATA3.0; 1* M.2

♦ Expansion: 1* M.2 for WIFI&BT; 1* 120-pin high-speed header(4* TTL, 2* PCIe, 1* SATA, 1* DP)

♦ Power: DC_12V input

Read More Make an inquiry
LGA1700 2 Lan H610 DDR4 19V Mini-ITX Form Factor
♦Model: ITX-YS610R1_6C VER:1.0

♦CPU: LGA1700 12th~14th Celeron/Pentium/Core™ i3/i5/i7/i9

♦Memory: Dual channel SO-DIMM DDR4 up to 64GB

♦Display: Intel® HD Graphics;DP+HDMI+LVDS displays

♦Ethernet: 2* RTL8111H GbE Ports

♦Storage: 2* SATA3.0; 1* M.2

♦Expansion: 1* M.2 for WIFI/BT

♦Power: DC_19V input

Read More Make an inquiry
4 Lan 2.5G DDR5 1U Firewalls and Network Security
♦Model: SII-NET-ATL-4LV_Z

♦CPU: Intel 12th Gen Alder Lake-N N97/ N150 Processors

♦Memory: 1x SO-DIMM DDR5-4800MHz slot,up to 48GB

♦Ethernet: 4x RJ45_2.5GbE (Intel I226V Ethernet Controller)

♦Storage: 1x M.2 SATA SSD + 1x SATA HDD slot

♦Expansion: 1x Mini-PCIE (for WIFI&BT)

♦Power Supply: AC 100-240V

Read More Make an inquiry
2 Lan Ryzen 7 8845HS DDR5 4K Display TPM AMD Motherboard
♦Model:ITX-YH853A1_R723L

♦Integrated AMD Ryzen 7 8845HS 3.8GHz 8-core 16-thread CPU

♦AMD Radeon 780M Graphics;LVDS +2*HD+1*eDP for Display

♦2*DDR5 5600MHz SO-DIMM socket,up to 64GB

♦2* RTL8111H Gigabit Eth/8*USB/2*COM(RS232/485)/1*TPM

♦1*M.2 NVME SSD/1* M.2(WIFI/BT)/1* 80-pin high-speed connector(4* PCIe, eSPI, USB, and DDI signals)

♦Support GPIO;Watchdog Timer;Audio power amplifier 4Ω/3W

♦Provide: DC 12~19V input

♦Size: 170mm x 170mm

Read More Make an inquiry
2 Lan Ryzen 5 7535HS DDR5 4K Display TPM Mainboard AMD
♦Model:ITX-YH753A1_R523L

♦Integrated AMD Ryzen 5 7535HS 3.3GHz 6-core 12-thread CPU

♦AMD Radeon 660M Graphics;LVDS+2*HD+1*eDP for Display

♦2*DDR5 4800MHz SO-DIMM socket,up to 64GB

♦2* RTL8111H Gigabit Eth/8*USB/2*COM(RS232/485)/1*TPM

♦1*SATA3.0/1*M.2 NVME SSD/1* M.2(WIFI/BT)/1* 80-pin high-speed connector(4* PCIe, eSPI, USB, and DDI signals)

♦Support GPIO;Watchdog Timer;Audio power amplifier 4Ω/3W

♦Provide:DC 12~19V power input

♦Size: 170mm x 170mm

Read More Make an inquiry
2 Lan DDR4 N100 Mini ITX Motherboard
♦Model No.: SBC-E100_LV62 VER:1.1(N100)

♦Based on Intel Alder Lake-N SOC platform

♦Integrated 12nd Gen Celeron N100 3.4GHz Quad core processor

♦Intel UHD Graphics ; LVDS1/ EDP1+VGA/ EDP2+HDMI for Display

♦1*DDR4 3200MHz SO-DIMM socket, up to 32GB

♦2*RJ45 Gigabit Eth / 10*USB / 6*COM(RS232/485/422) / 1*LPT

♦1*SATA3.0 / 1*M.2 SSD / 1*MINI_PCIE for WIFI/4G

♦Support GPIO ; Watchdog Timer ; ALC897 High-Definition Audio Chip

♦Support DC_12V Input

Read More Make an inquiry
4 Lan I226 2.5G N100 DDR4 Fanless Firewall Mini Pc
♦Model No.:SII-G31X-1264-4L2C

♦Fanless design, Aluminum alloy Chassis

♦Intel®Alder Lake-N N100 3.4GHz quad-core CPU

♦1*DDR4 RAM slot, up to 16GB

♦1*M.2 NVMe (2280); 1*SATA 6.0Gb/s (Support 2.5 inch HDD/SSD)

♦4*i226 2.5 Gigabit Lan

♦1*DP; 1*HD

♦1*Mini-PCIe for WiFi/BT/4G

♦2x USB3.0, 4x USB2.0

♦DC_12V Power Input

Read More Make an inquiry
LGA1700 DDR4 Dual HDMI 19V Embedded Industrial Mini ITX Motherboard
♦Model: ITX-B610_2C VER:1.0

♦Intel H610 chipset

♦Supports LGA1700 12th/13th/14th Celeron/Pentium/Core i3/i5/i7/i9 processor

♦Integrated Intel HD Graphics;VGA+2*HD+LVDS for display

♦2*DDR4 3200MHz SO-DIMM socket,up to 64GB

♦1* RTL8111H Gigabit Ethernet/8*USB/2*COM(RS232/485/422)

♦2*SATA3.0/1*M.2(2260/2280 NVME PCIE3.0 X4)/1*M.2(for Key E 2230 WIFI&BT)

♦Support Win10/Win11/Linux; Watchdog Timer

♦Provide:DC19V power supply

♦Size: 170mmx170mm

Read More Make an inquiry
6 Lan I226-V 2.5G N100 DDR4 1U Firewall Hardware Appliance
♦ Model: SII-F6L-P

♦ 1U/2U Standard Rack_mount Chassis

♦ Intel N100/N150/N305processors

♦ 1x DDR4 RAM slot, up to 16GB

♦ 1x SATA3.0 + 1x MSATA

♦ 6x 2.5GbE Ports (I226)

♦ 1x PCI-E x8 slot

♦ 1x Mini-pcie/MSATA/M.2 (Wifi&BT&4G/5G LTE)

♦ 2x USB2.0 ; 2x USB2.0 pin(inner)

♦ AC IN 100-240V

Read More Make an inquiry
N95 I226V 2.5G 4 Lan DDR5 4K Display NVME TPM Fanless Mini Firewall Appliance
♦Model: SII-ADLN--ZY

♦Aluminum Alloy ; Passive Cooling

♦Intel N95/N100/N150/N305 CPUs

♦1*DDR5 RAM slot, up to 48GB

♦1*SATA3.0 + 1*M.2 NVMe

♦4*2.5GbE Ports (I226V)

♦2*HD+1*Type-C 4K Display

♦1*TF slot;1*SIM card slot

♦M.2 B-KEY + M.2 E-KEY (for WIFI/4G MODULE)

♦4*USB2.0 ; 1*USB3.2

♦DC_12V Power Input

♦Size: 158.2mm*137mm*61.23mm

Read More Make an inquiry
