  • 4 Lan N97 DDR4 Fanless Mini Firewall
    ♦Model No.:C2120Z-L4  V2.0(N97)
    ♦All aluminum alloy, fanless cooling structure
    ♦Intel®Alder Lake-N N97/Turbo 3.6GHz quad-core CPU
    ♦1x DDR4 RAM slot, up to 16GB
    ♦1x SATA + 1x M.2
    ♦4x RJ45 Lan
    ♦1x HDMI1.4
    ♦1x Mini-PCIe for 4G/WIFI
    ♦5x USB3.0, 1x USB2.0
    ♦DC_12V Power Input
  • 8 Lan LGA1151 DDR4 SFP Pfsense Firewall System Security
    Model No.:R320E-L8 V1.0(R270)
    ♦ Intel®LGA1151 6th/7th/8th/9th i3/i5/i7 series processor
    ♦ Intel®Q270/Q250 High speed chipset
    ♦ 2*DDR4 SODIMM 2400MHz ,max up to 64GB
    ♦ 8*Intel I210 Gigabit Ethernet port,4 or 2 SFP+ ports can be extended
    ♦ 2*USB3.0, 1*VGA
    ♦ 4 or 2 light ports can be extended
    ♦ Support two groups of BYPASS(Optional)
    ♦ Standard with 1U AC220V ATX power supply 250W
    ♦ 1U standard case, high-quality galvanized steel plate / Support Windows&Linux OS
  • 4 Lan N97 DDR4 Machine Vision Motherboard
    Model No.:ITX-VL305 VER:1.0(N97)
    ♦Based on Inte Alder Lake-N SOC platform
    ♦Integrated Intel®Alder Lake-N N97 3.6GHz quad-core processor
    ♦Intel® UHD Graphics; VGA+HDMI+LVDS/1* EDP for display
    ♦1*DDR4 2133MHz SO-DIMM Socket, up to 16GB
    ♦4* Intel WGI210AT Gigabit Ethernet/ 8*USB/ 6*COM /1*SIM/ 1* TPM
    ♦1*SATA3.0/ 1* M.2 SSD/ 1* Mini-PCIE (Wifi/4G)
    ♦Support GPIO ; Watchdog Timer ; Audio power amplifier 4Ω/3W
    ♦Support DC_12V Input
  • RK3576 ARM Motherboard
    Model No.:CX3576-A V1.0 (4G+128G)  VER:4G
    ♦WIFI use FCS960K,support 2.4G/5G dual-band,Bluetooth5.3
    ♦Bottom plate thread DC2.0*1(12V-36V input)
    ♦RJ45*1、HDMI*1、USB3.0*1、USB2.0*1、USB2.0 socket*4、TF*1、Audio 3.5mm*1
    ♦Size:157*100mm
  • 6 Lan LGA1151 2U Rackmount Dual Power Pfsense Firewall Appliance

    6 Lan LGA1151 2U Rackmount Dual Power Pfsense Firewall Appliance

    Model No.:STCW-B250
    ♦6*Intel i225-V B3 2.5G electric port
    ♦Support 2*Intel 82599 dual 10G optical ports
    ♦Support 4*Intel XL710 40G optical port
    ♦Dual SO-DIMM slot;up to 64GB
    ♦Support Intel 6/7/8/9 gen Core processor
    ♦Support redundant 1+1 dual power supply solution
  • 6 Lan LGA1151 1U Rackmount Dual Power Network Firewall Router

    6 Lan LGA1151 1U Rackmount Dual Power Network Firewall Router

    Model No.:STCW-B250
    ♦6*Intel i225-V B3 2.5G electric port
    ♦Support 2*Intel 82599 dual 10G optical ports
    ♦Support 4*Intel XL710 40G optical port
    ♦Dual SO-DIMM slot;up to 64GB
    ♦Support Intel 6/7/8/9 gen Core processor
    ♦Support redundant 1+1 dual power supply solution
  • 3 Lan Xeon 2U Rackmount Dual Power Network Firewall Device

    3 Lan Xeon 2U Rackmount Dual Power Network Firewall Device

    Model No.:STCW-NET-C612
    ♦Equipped with two Intel Xeon E5-v3/v4 series processors
    ♦8*DIMM DDR4 REG ECC memory slot; up to 256G
    ♦2*M.2 NVMe/8*SATA3.0/1*mSATA/1*CF
    ♦The panel bezel supports 3 PCI-Ex8 expansion slots
    ♦Support dual-port/quad-port/1G/2.5G/10G/40G 10G optical expansion
    ♦The chassis has three 8025 double ball cooling fans for more powerful heat dissipation
    ♦2U rack-mounted design with reserved guide rail positions for 600mm deep cabinets
    ♦Supports two power supply modes: single power supply or redundant 1+1 dual power supply
  • 3 Lan  Xeon 1U Rackmount Dual Power Pfsense Firewall Router SFP 10G

    3 Lan Xeon 1U Rackmount Dual Power Pfsense Firewall Router SFP 10G

    Model No.:STCW-NET-C612
    ♦Equipped with two Intel Xeon E5-v3/v4 series processors
    ♦8*DIMM DDR4 REG ECC memory slot; up to 256G
    ♦2*M.2 NVMe/8*SATA3.0/1*mSATA/1*CF
    ♦The panel bezel supports 3 PCI-Ex8 expansion slots
    ♦Support dual-port/quad-port/1G/2.5G/10G/40G 10G optical expansion
    ♦The chassis has three 8025 double ball cooling fans for more powerful heat dissipation
    ♦2U rack-mounted design with reserved guide rail positions for 600mm deep cabinets
    ♦Supports two power supply modes: single power supply or redundant 1+1 dual power supply
  • 6 Lan i3-12100 2U Rackmount Dual Power Pfsense Firewall Router

    6 Lan i3-12100 2U Rackmount Dual Power Pfsense Firewall Router

    Model No.:STCW-NET-B660
    ♦B660 chipset supports Intel 12th/13th/14th generation desktop processors
    ♦The PCI-Ex16 slot on the left side of the motherboard supports expansion of application cards or network cards
    ♦Support dual-port/quad-port/1G/2.5G/10G/40G 10G optical expansion card
    ♦Dual M.2 NVMe/quad SATA3.0/mSATA three storage interfaces
    ♦2*SO-DIMM DDR4 memory slots, dual channel, maximum 64G
    ♦The motherboard 4PIN/DC port power supply supports 19-24V or DC 24V power supply
    ♦Optional support for single power supply or 1U redundant dual power supply module
    ♦2U case with 3*8025 ball bearing fans for stronger heat dissipation
  • 6 Lan i3-12100 1U Rackmount Dual Power Network Firewall Security

    6 Lan i3-12100 1U Rackmount Dual Power Network Firewall Security

    Model No.:STCW-NET-B660
    ♦B660 chipset supports Intel 12th/13th/14th generation desktop processors
    ♦The PCI-Ex16 slot on the left side of the motherboard supports expansion of application cards or network cards
    ♦Support dual-port/quad-port/1G/2.5G/10G/40G 10G optical expansion card
    ♦Dual M.2 NVMe/quad SATA3.0/mSATA three storage interfaces
    ♦2*SO-DIMM DDR4 memory slots, dual channel, maximum 64G
    ♦The motherboard 4PIN/DC port power supply supports 19-24V or DC 24V power supply
    ♦Optional support for single power supply or 1U redundant dual power supply module
    ♦2U case with 3*8025 ball bearing fans for stronger heat dissipation
  • 8 Lan i3-8100 2U Dual Power Firewall Network Appliance

    8 Lan i3-8100 2U Dual Power Firewall Network Appliance

    Model No.:STCW-NET-C246
    ♦Compatible with Intel 8th/9th gen Core and Xeon E-2100 series processors
    ♦Dual channel SO-DIMM DDR4 memory slot; up to 64G
    ♦Support M.2 NVMe/mSATA/SATA three storage methods
    ♦The panel baffle supports two PCI-Ex8 expansion slots
    ♦Support dual-port/quad-port/1G/2.5G/10G/40G 10G optical card expansion
    ♦Optional support for single power supply and 1U redundant dual power supply
    ♦Case chassis three 4020 double ball cooling fans
  • 8 Lan i3-8100 1U Dual Power Network Security Appliance

    8 Lan i3-8100 1U Dual Power Network Security Appliance

    Model No.:STCW-NET-C246
    ♦Compatible with Intel 8th/9th gen Core and Xeon E-2100 series processors
    ♦Dual channel SO-DIMM DDR4 memory slot; up to 64G
    ♦Support M.2 NVMe/mSATA/SATA three storage methods
    ♦The panel baffle supports two PCI-Ex8 expansion slots
    ♦Support dual-port/quad-port/1G/2.5G/10G/40G 10G optical card expansion
    ♦Optional support for single power supply and 1U redundant dual power supply
    ♦Case chassis three 4020 double ball cooling fans
  • 8 Lan i3-6100 2U Dual Power SFP Firewall Network Appliance

    8 Lan i3-6100 2U Dual Power SFP Firewall Network Appliance

    Model No.:STCW-NET-C236
    ♦Compatible with Intel 6th/7th/8th/9th generation LGA1151 series CPU processors
    ♦Native 8*Intel i226-V 2.5G, customizable 8*i210/i210 Gigabit Ethernet ports
    ♦Supports up to i9-9900 8-core 16-thread processor and E3 V5 series processor
    ♦PCI-E x8 slot supports expansion of 4 network ports/dual 10 Gigabit optical ports/40 Gigabit optical ports
    ♦1U/2U rackmount chassis optional, 2U has stronger heat dissipation
    ♦2U chassis supports single power supply/redundant dual power supply
    ♦The motherboard reserves BYPASS pads to support customized LAN1-4 two sets of BYPASS
  • 8 Lan i3-6100 1U 2 Power Network Firewall Security

    8 Lan i3-6100 1U 2 Power Network Firewall Security

    Model No.:STCW-NET-C236
    ♦Compatible with Intel 6th/7th/8th/9th generation LGA1151 series CPU processors
    ♦Native 8*Intel i226-V 2.5G, customizable 8*i210/i210 Gigabit Ethernet ports
    ♦Supports up to i9-9900 8-core 16-thread processor and E3 V5 series processor
    ♦PCI-E x8 slot supports expansion of 4 network ports/dual 10 Gigabit optical ports/40 Gigabit optical ports
    ♦1U/2U rackmount chassis optional, 2U has stronger heat dissipation
    ♦2U chassis supports single power supply/redundant dual power supply
    ♦The motherboard reserves BYPASS pads to support customized LAN1-4 two sets of BYPASS
  • 8 Lan LGA1151 2U Dual Power SFP Network Firewall

    8 Lan LGA1151 2U Dual Power SFP Network Firewall

    Model No.:STCW-NET-B150
    ♦Compatible with Intel 6th/7th gen LGA1151 series CPU processors
    ♦8*native Inteli226-V2.5G, 8*customizable i210 Gigabit Ethernet ports
    ♦PCI-E x8 supports expansion of four network ports/four 1000M optical ports/dual 1000M optical ports/4000M optical ports
    ♦1U/2U rackmount chassis optional, 2U has stronger heat dissipation
    ♦1U/2U chassis supports single power supply/redundant dual power supply solutions
    ♦2U chassis supports single power supply/redundant dual power supply
    ♦The motherboard reserves BYPASS pads to support customized LAN1-4 two sets of BYPASS
  • 8 Lan LGA1151 1U Dual Power Firewalls and Network Security

    8 Lan LGA1151 1U Dual Power Firewalls and Network Security

    Model No.:STCW-NET-B150
    ♦Compatible with Intel 6th/7th gen LGA1151 series CPU processors
    ♦8*native Inteli226-V2.5G, 8*customizable i210 Gigabit Ethernet ports
    ♦PCI-E x8 supports expansion of four network ports/four 1000M optical ports/dual 1000M optical ports/4000M optical ports
    ♦1U/2U rackmount chassis optional, 2U has stronger heat dissipation
    ♦1U/2U chassis supports single power supply/redundant dual power supply solutions
    ♦2U chassis supports single power supply/redundant dual power supply
    ♦The motherboard reserves BYPASS pads to support customized LAN1-4 two sets of BYPASS
