Products

New Products

•
  4 Lan N97 DDR4 Fanless Mini Firewall Router

  ♦Model No.:C2120Z-L4  V2.0(N97)

  ♦All aluminum alloy, fanless cooling structure

  ♦Intel®Alder Lake-N N97/Turbo 3.6GHz quad-core CPU

  ♦1x DDR4 RAM slot, up to 16GB

  ♦1x SATA + 1x M.2

  ♦4x RJ45 Lan

  ♦1x HDMI1.4

  ♦1x Mini-PCIe for 4G/WIFI

  ♦5x USB3.0, 1x USB2.0

  ♦DC_12V Power Input
•
  8 Lan LGA1151 DDR4 SFP Pfsense System Security Firewall Device

  ♦ Model No.:R320E-L8 V1.0(R270)

  ♦ Intel®LGA1151 6th/7th/8th/9th i3/i5/i7 series processor

  ♦ Intel®Q270/Q250 High speed chipset

  ♦ 2*DDR4 SODIMM 2400MHz ,max up to 64GB

  ♦ 8*Intel I210 Gigabit Ethernet port，4 or 2 SFP+ ports can be extended

  ♦ 2*USB3.0, 1*VGA

  ♦ 4 or 2 light ports can be extended

  ♦ Support two groups of BYPASS(Optional)

  ♦ Standard with 1U AC220V ATX power supply 250W

  ♦ 1U standard case, high-quality galvanized steel plate / Support Windows&Linux OS
•
  4 Lan N97 DDR4 Machine Vision Motherboard

  ♦Model No.:ITX-VL305 VER:1.0(N97)

  ♦Based on Inte Alder Lake-N SOC platform

  ♦Integrated Intel®Alder Lake-N N97 3.6GHz quad-core processor

  ♦Intel® UHD Graphics; VGA+HDMI+LVDS/1* EDP for display

  ♦1*DDR4 2133MHz SO-DIMM Socket, up to 16GB

  ♦4* Intel WGI210AT Gigabit Ethernet/ 8*USB/ 6*COM /1*SIM/ 1* TPM

  ♦1*SATA3.0/ 1* M.2 SSD/ 1* Mini-PCIE (Wifi/4G)

  ♦Support GPIO ; Watchdog Timer ; Audio power amplifier 4Ω/3W

  ♦Support DC_12V Input
•
  RK3576 ARM Motherboard

  ♦Model No.:SII-3576-A V1.0  VER:4G

  ♦Based on RK3576 SOC platform

  ♦Integrated Four Cortex-A72+Four Cortex-A53 64-bit CPU, Highest frequency 2.2GHz

  ♦HD + EDP + LVDS + MIPI for Display

  ♦Onboard LPDDR4 8GB memory 8GB ( 4GB/16GB Optional)

  ♦6 serial sockets (2*RS232,1*485,1*TTL,2*RS232/RS485)

  ♦Built-in Wi-Fi,BT5.3 supports dual-band Wi-Fi, single antenna.

  ♦4G module holder with built-in MINI PCIE interface, supporting voice calls.

  ♦1*DC 12~36V Input ; OS: Android14, Linux6.1, Debian12 , Ubuntu22.04

  ♦ Size: 157mm x 100mm
