Features
Powered by an Intel J4105 (quad-core, 10W), this device is a professional 4 Lan Multi-gigabit Firewall Appliance. It features 4 Intel i210/i226 network ports with hardware BYPASS, up to 32GB DDR4 RAM, and multiple storage options (SATA/mSATA/M.2). It also offers rich expansion (SIM, Mini-PCIe, RS485, GPIO) and comes in 9-inch desktop or 1U rackmount chassis.
Applications:
1.Network Security: Enterprise firewall, VPN, and gateway.
2.Soft Routing: pfSense/OpenWrt for multi-WAN load balancing.
3.Industrial IoT: Factory automation and data acquisition (RS485/GPIO).
4.Wireless Edge: 4G/5G in-vehicle or surveillance gateway.
5.Traffic Auditing: Network logging and video storage.
Product Description
Main:
CPU: Intel® J4105
Code Name: Gemini Lake
Memory: 1* SO-DIMM DDR4 2400 / 2666 / 3200MHz MAX 32GB
LAN:
IC: Intel® Ethernet Controller i210-AT / i226-V
Speed: 100/1000Mbps/2.5G adapting
Interface: 4* 1G/2.5Gbps Ethernet Controller, RJ45
Storage: 1* SATA / 1* mSATA
Display: 1* VGA
BIOS: AMI UEFI BIOS
USB: 2* USB3.0 interface; 2* USB2.0(Array pin)
Power Supply:
Voltage: 100-240V~50/60Hz
Mainboard: ATX 4Pin 12V / DC-12V 55mm*25mm
Other:
GPIO: 8* programmable GPIO
Watchdog: 255 Levels, 0-255 Seconds
COM: 1* RJ45 Console / 1* COM (Array pin)
4G/5G/WiFi: 1* miniPCle / 1* M.2 B_key
Other: NetWork WakeUp / PXE
Dimension:
Desktop: 197mm*174mm*44mm
1U: 440mm*255mm*45mm
PCB: 170mm(W) * 170mm(L)
Working Temperature: 0℃~60℃
Storage Temperature: -10℃~70℃
Working Humidity: 10%~90%
Storage Humidity: 5%~95%, non-condensing
OS: Windows10 / 11,Windows Server, Linux
.png)
.png)
Application
We have a comprehensive layout in the fields of smart loT and cloud computing.Our products have been widely used in industrial equipment automation (intelligent manufacturing), self-service terminal, network security, digital signage, medical equipment (medical imaging), intelligent terminal, intelligent transportation, cloud server, cloud storage, machine vision, robot, intelligent kiosk, GPS navigation, instrumentation, Government agencies, telecommunications, banking, electricity, vehicle automation (control and display), monitors, video doorbells, portable computers, intelligent teaching, environmental protection equipment, etc.
.jpg)
Packing & Delivery
We have a wide range of transportation options to choose from. No matter where you are, our transportation options can meet your needs.
Company Profile
FAQ
Q1.Do you accept OEM / ODM order?
A1:Of course, we have our own R&D team that support customization on motherboard design, test and produce.
Q2:What payment method do you accept?
A2:We accept T/T,MoneyGram,Paypal, Western Union is all ok.
Q3:How long is the warranty of your products?
A3:we offer 2 years warranty for all of our products.
Q4:How many days will samples be finished? And how about the mass production?
A4:Samples will be deliver within 3 working days,after payment received. The leading time of mass production will depend on the quantity.
Q5:If we come to China,can you arrange the visiting to your factory?
A5:We warmly welcome and look forward to your visiting to our factory at any time.
