Overview
This high-performance
Firewall Appliance
is built on Intel® B660 chipset, supporting 12th/13th/14th Gen Core processors (i3/i5/i7). It features 6 x Intel® i226-V 2.5G Ethernet RJ45 ports, 2 x DDR4 SO-DIMM slots (up to 64GB), dual M.2 NVMe storage (PCIe4.0 x4 + PCIe3.0 x4), 4 x SATA3.0, 1 x mSATA, VGA + HDMI display outputs, 2 x USB3.2 + 5 x USB2.0, RJ45 Console + 2 COM headers, 8 programmable GPIO, watchdog timer, M.2 B-key for 4G/5G/WiFi, PCIe expansion slots supporting optional 2.5G/1G copper or 10G SFP+ fiber modules, plus Wake-on-LAN and PXE. Powered by 19-24V DC input, available in 1U/2U chassis.
This Firewall Appliance delivers exceptional throughput for Next-Generation Firewall (NGFW) , UTM, VPN gateway, DPI deep packet inspection, and SD-WAN edge routing. With 0℃~60℃ wide-temperature operation and dual M.2 NVMe for high-speed caching, it is ideal for enterprise network perimeter defense, data center security aggregation, telecom edge nodes, and industrial IoT security gateways. Its flexible PCIe expansion (supporting 10G SFP+) and 2.5G multi-WAN aggregation make it a future-proof hardware platform for carrier-grade cybersecurity and high-traffic critical infrastructure protection.
Product Description
Main:
CPU:
Intel-12th：i3-12100 / i5-12400 / i7-12700
Intel-13th：i3-13100 / i5-13400 / i7-13700
Intel-14th：i3-14100 / i5-14400 / i7-14700
Code Name: Intel® 12th Alder Lake / Intel® 13-14th Raptor Lake
Chipset: Intel® B660
Memory: 2* SO-DIMM DDR4 2400/2666/3200MHz MAX 64G
LAN:
IC: Intel® i226-V
Speed: 2500Mbps 2.5G adapting
Interface: 6 * Intel® Ethernet Contoller 2.5G RJ45
Support NetWork WakeUp / PXE
Storage:
1* M.2 NVMe 2280 PCle4.0 x4 / 1* M.2 NVMe 2280 PCle3.0 x4
4* SATA3.0 6Gbps / 1* mSATA
Display: 1* VGA / 1* JHDMI(Array pin)
BIOS: AMI UEFI BIOS EFI
USB: 2* USB3.2; 1* USB2.0(Vertical) / 4* USB2.0(Array pin)
Power Supply:
Voltage: 100-240V~50 / 60Hz
Power mode: 4Pin 19-24V / DC19-24V 55mm*25mm
GPIO: 8* programmable GPIO
Watchdog: 255 Levels, 0-255 Seconds
COM: 1* RJ45 Console / 2* COM (Array pin)
4G/5G/WiFi: 1* M.2 B key
Dimension:
1U: 440mm*320mm*45mm
2U: 435mm*440mm*90mm
Working Temperature: 0℃~60℃
Storage Temperature: -10℃~70℃
Working Humidity: 10%~90%
Storage Humidity: 5%~95%, non-condensing
OS: Windows10 / 11,Windows Server, Linux
Application
We have a comprehensive layout in the fields of smart loT and cloud computing.Our products have been widely used in industrial equipment automation (intelligent manufacturing), self-service terminal, network security, digital signage, medical equipment (medical imaging), intelligent terminal, intelligent transportation, cloud server, cloud storage, machine vision, robot, intelligent kiosk, GPS navigation, instrumentation, Government agencies, telecommunications, banking, electricity, vehicle automation (control and display), monitors, video doorbells, portable computers, intelligent teaching, environmental protection equipment, etc.
.jpg)
Packing & Delivery
We have a wide range of transportation options to choose from. No matter where you are, our transportation options can meet your needs.
Company Profile
FAQ
Q1.Do you accept OEM / ODM order?
A1:Of course, we have our own R&D team that support customization on motherboard design, test and produce.
Q2:What payment method do you accept?
A2:We accept T/T,MoneyGram,Paypal, Western Union is all ok.
Q3:How long is the warranty of your products?
A3:we offer 2 years warranty for all of our products.
Q4:How many days will samples be finished? And how about the mass production?
A4:Samples will be deliver within 3 working days,after payment received. The leading time of mass production will depend on the quantity.
Q5:If we come to China,can you arrange the visiting to your factory?
A5:We warmly welcome and look forward to your visiting to our factory at any time.
